Availability: | |
---|---|
Quantity: | |
ITEM | PB1300 |
Light | |
Housing Material | Aluminium die cast |
Power of lights | 3×1000W Metal halide lamp |
Lumen Output | 3×110,000lm ( total ) |
Voltage | AC 220-240V |
Frequency | 50/60Hz |
Lifetime of lamps | 8000 Hrs |
Waterproof grade | IP65 |
Color temperature | 4000K |
Mast | |
Material of mast | Galvanized steel |
Mast lifting type | Manual mast |
Mast rotation system(Lamp bracket) | 358° manual operation |
Mast section | 4 |
Max. height of mast | 5.1 meters |
Gasoline Generator | |
Type | HONDA EG5000CX |
Engine model | GX340H1 : Single cylinder 4-stroke air cooled |
Start system | Recoil (Hand start) |
Alternator | Brushless AC Generator / Single Phase |
Rated power | 50hz/4.0KVA |
Max power | 4.5KVA |
Fuel tank capacity | 24L |
Fuel consumption | 2.5L/hr |
Operating hours | 9.5hrs |
Voltage regulator | Voltage regulator |
Circuit breaker system | Electro magnetic |
Trolley | |
Stabiliser Supports | 2×Manual |
Number of Tires | 4 |
Tire Size | 3.50-5 pneumatic tire (diameter 10.6 inch) |
Brakes | Manual |
Packing | |
Net weight | 239kg |
Dimension | 1,160×830×1,800 mm |
