PB1600THW-LED

SPECIFICATION
ELECTRICAL
• Power Input : AC 200 - 277V
• Frequency : 50/60 Hz
• Power Factor(PF) : > 0.96
•Total Harmonic Distortion : < 15%

OPTICS
• Lumen output (@5700K) : 60,000 lm
• Efficacy : 150 lm/W
• Replacement : MH 1 kW
• CCT(K) : Standard-3000/5700, Option-2700/4000/5000
• LED Package Life time : 50,000 hours (25℃)
※ LED package life time according to industry standard (LM80).
    ※ High operating temperature may shorten life span of LED package and LED lamp.

HIGH PERFORMANCE
• Designed for 1:1 retrofit with self-ballasted internal driver
• LED replacement for 1kW MH with 60% electricity saving
• IP67 available for outdoor waterproof usage
• Compact & versatile design with 360° installation angle
• Various lens options to achieve the optimal illumination
• Circular LED array for excellent luminance uniformity
• Flicker-free for eye comfort
• Embedded fire protection system and surge protector
•Superb heat dissipation

WHY LITEMAN
Highly Efficient heatsink was created by Fluid Dynamic Pressure Technology, which enables heat dissipation 200 times faster (40,000 W/m∙K) than that of conventional aluminum (Al) heatsink. Liquid circulation takes place inside the pipe, traveling through the coil and cooling down heat from the LEDS in the most efficient way.

•The fastest heat transfer rate
•Efficient air flow
•Uses light weight copper
