Product Detail

PB1600THWHL

●Metal halide lamp, 1000W x 6 lamps, total brightness 660000lm, effective irradiation distance 450 m.
●Aluminium alloy casting square lamp, more durable, more fashionable, independent lamp switch for each light.
●Electric control rolling-over- for lamp assembly.mast36 rotation, light bar120° tumover full range lighting .
Fuel tank capacity: 105L, can use more than 37 hours continuously: Support 220 VAC power.
●3 stages hydraulic mast up to 9.2m.
●Standard configuration High performance off-road tires 225/70R16; High efficiency shock absorbed rubber torsion shaft.
●Five out rigger support legs, thickened box, can be decomposed.
●Full hydraulic leg.
●Standard color: White, Note: Optional color.
●Power model: PERKINS or Original import KUBOTA diesel engine, electrical starter, output power 12.8KVA .
●Engine with oil and water temperature protection device, three cylinders, Rated speed 1500RPM.
●Rated power:8.6KVA, Max power:9.3KVA: Insulation grade: H.
Availability:
Quantity:
  • PB1600THWHL
  • Powerbaby/LITEMAN
  • 9405409000

ITEM

PB1600THWHL

Light

Housing Material

Aluminium die cast

Power of lights

6×1000W Metal halide lamp

Lumen Output

6×110,000lm ( total )

Voltage

AC 220-240V

Frequency

50/60Hz

Lifetime of lamps

8000 Hrs

Waterproof grade

IP65

Color temperature

4000K

Mast

Material of mast

Stainless steel

Mast lifting type

Hydraulic mast

Mast rotation system

358° manual operation

Mast section

3

Max. height of mast

9.2 meters

Light bar rotation

120° Electrical waving

Diesel Engine

model

Kubota D1703, 3 cylinder, 4-stroke, water cooled

Start system

Electric (Battery start)

Engine speed

50hz/1500rpm,

Rated power

50hz/12.8kw

Fuel tank capacity

Auxiliary oil tank:105L

Fuel consumption

2.8L/hr

Controller system

Digital control panel

Generator

model

STAMFORD PI0 44H

Rated  power

9.4kw

Rated frequency

50hz

Rated Voltage

220V

Insulation class

H

Electrical protection system

Automatic

Trailer

Stabiliser Supports

4×Hydraulic

Tow Hitch

Ring/ball hitch

Tire Size

16inch

Brakes

Manual

Packing

Net weight

1,350kg

Dimension

4,570X1,750X2,100 mm
